Chitagni

Portable cremator

Chitagni is a portable and mobile crematorium designed for dignified and eco-friendly cremation in remote and emergency conditions. It ensures respectful final rites while reducing environmental impact and supporting disaster response where permanent facilities are unavailable.

Specification

Material used

Chamber: Special-grade stainless steel with high thermal resistance and excellent corrosion resistance. Corpse Bed: Special-grade stainless steel with exceptional thermal resistance and outstanding corrosion resistance. It is designed to be removable for flexibility during the cremation process.

Dimensions

Overall Size: 2190 x 900 x 1500 Chamber: 1980 x 740 x 1500

Maximum Operating Temperature:

1150°C ± 100°C

Chamber Doors

There are a total of three doors in the chamber. One opening is designed for collecting ashes from the ash tray, and the other two are for viewing the progress of cremation.

Electric Blower

Connected with electric blower to reduce gas consumption

Gas-based System

Connected with electric blower to reduce gas consumption. Gas-based System Fuel: LPG or CNG Burner: Italian burner with high-efficiency for precise and controlled combustion. LPG Gas installation includes reduction and emission control to comply with environmental regulations. LPG Connection: 2 inlets for 12 or 20 Kg Cylinders

Portability and Mobility

Trailer-Mounted: Equipped with sturdy wheels and a hitch for easy transportation. Weight: 380 Kg for hassle-free manoeuvrability.

Operating Parameters

Cremation Time: 45 to 60 minutes for standard cremations. Fuel Consumption: 12kg LPG for standard cremation.

Power Requirements for blower

Voltage: 220V

Frequency: 50Hz

Horsepower: 1.5HP

Four pillars of purity

Zero Water Contamination

Immersion and immersion-based pyres often lead to the pollution of rivers, lakes, and other water bodies, degrading the purity of our vital water sources.We protect watersheds from both chemical and biological runoff associated with open air traditional pyres.

Absolute Soil Integrity

Traditional cremations often involve the direct contact of burning bodies or ashes with the earth, resulting in soil contamination, sterilization, and loss of fertility. DADG’s system ensures zero contact with the earth, maintaining 100% soil integrity and enabling organic growth.
Eliminates soil vitrification and chemical leaching, keeping the land under the unit 100% pollution-free.

Forest Preservation

Every traditional cremation requires nearly half a ton of wood, directly contributing to large-scale deforestation. By using DADG’s technology, we completely eliminate this need, preventing the felling of trees and saving our planet’s forests.
Each Cremation saves 500-700 Kg of wood, preventing the destruction of vital forest cover.

Drastic Carbon Reduction

Wood-based cremations release massive volumes of CO₂ and other harmful greenhouse gases into the atmosphere. DADG’s circular system technology for cremation ensures that there is no release of emissions, offering an alternative that negates this impact entirely.
Reduces greenhouse gas emissions by over 90% compared to traditional open/ritual wood cremation methods.Eliminates soil vitrification and chemical leaching, keeping the land under the unit 100% pollution-free.
